CAT 6 S/FTP PATCH CORDS

Schnell Cat6 S/FTP patch cords deliver premium Category 6/Class E performance up to 250 MHz. Built with individually foiled twisted pairs and an overall tinned copper braid, they ensure exceptional EMC, alien‑crosstalk suppression, and Gigabit Ethernet support. Available in LSZH or PVC jackets, with over‑molded boots and strain‑relief caps, each cord is factory‑tested for insertion and return loss.



📥 DOWNLOAD DATASHEET



Description

Schnell Cat6 S/FTP patch cords deliver premium Category 6/Class E performance up to 250 MHz. Built with individually foiled twisted pairs and an overall tinned copper braid, they ensure exceptional EMC, alien crosstalk suppression, and Gigabit Ethernet support. Available in LSZH or PVC jackets, with over molded boots and strain relief caps, each cord is factory tested for insertion and return loss.


Key Features

  • Individually foil‑shielded pairs + braided shield for superior EMC
  • LSZH or PVC jacket with over‑molded snag‑resistant boot
  • Supports Gigabit Ethernet with low insertion/return loss
  • Suitable for PoE/PoE+, tested 1000 mating cycles

Key Applications

  • High-performance LANs, Gigabit Ethernet backbones
  • EMI-prone environments like industrial areas or data centers
  • Structured cabling and patch panels
  • PoE/PoE+ deployments

Standards

  • IEEE 802.3af / 802.3at PoE certified
  • ANSI/TIA‑568.2‑D & ISO/IEC‑11801 Class E
  • IEC 61156‑2 Category 6
  • EN 50173 & EN 50288‑6‑2
  • UL 444 & UL Verified for patch cords

Part Numbers

Part Number Description Outer Jacket Material
SCZ-5010C6PCS0012GY SCHNELL CAT6 S/FTP PATCH CORD 0.12 MTR GREY PVC/LSZH
SCZ-5010C6PCS0015GY SCHNELL CAT6 S/FTP PATCH CORD 0.15 MTR GREY PVC/LSZH
SCZ-5010C6PCS002GY SCHNELL CAT6 S/FTP PATCH CORD 0.2 MTR GREY PVC/LSZH
SCZ-5010C6PCS003GY SCHNELL CAT6 S/FTP PATCH CORD 0.3 MTR GREY PVC/LSZH
SCZ-5010C6PCS005GY SCHNELL CAT6 S/FTP PATCH CORD 0.5 MTR GREY PVC/LSZH
SCZ-5010C6PCS01GY SCHNELL CAT6 S/FTP PATCH CORD 1 MTR GREY PVC/LSZH
SCZ-5010C6PCS02GY SCHNELL CAT6 S/FTP PATCH CORD 2 MTR GREY PVC/LSZH
SCZ-5010C6PCS03GY SCHNELL CAT6 S/FTP PATCH CORD 3 MTR GREY PVC/LSZH
SCZ-5010C6PCS05GY SCHNELL CAT6 S/FTP PATCH CORD 5 MTR GREY PVC/LSZH
SCZ-5010C6PCS10GY SCHNELL CAT6 S/FTP PATCH CORD 10 MTR GREY PVC/LSZH
SCZ-5010C6PCS15GY SCHNELL CAT6 S/FTP PATCH CORD 15 MTR GREY PVC/LSZH
SCZ-5010C6PCS20GY SCHNELL CAT6 S/FTP PATCH CORD 20 MTR GREY PVC/LSZH
SCZ-5010C6PCS25GY SCHNELL CAT6 S/FTP PATCH CORD 25 MTR GREY PVC/LSZH
SCZ-5010C6PCS30GY SCHNELL CAT6 S/FTP PATCH CORD 30 MTR GREY PVC/LSZH

MATERIAL CONSTRUCTION

Parameter Specification
Conductor Stranded bare annealed copper, 26 AWG
Pair Insulation SFS PE
Individual Pair Shield Aluminum-polyester foil
Overall Shield Tinned copper braid (≈ 45%)
Drain Wire Integral
Outer Jacket & Boots LSZH or PVC
Boot Design Over-molded anti-snag with strain relief
Outer Diameter ≈ 6.0 ± 0.2 mm
Cable Color Customizable (standard: grey / white / black)
Wire Map T568B

CHARACTERISTICS

ELECTRICAL CHARACTERISTICS
Impedance

DC Resistance

Contact Resistance

Resistance Unbalance

Voltage Rating

Dielectric Strength

Insulation Resistance

Pair‑to‑Ground Capacitance

Propagation Delay Skew

: 100 Ω ±15 Ω @ 1–250 MHz

: < 73 Ω/km

: ≤ 20 mΩ per contact

: ≤ 2 %

: 150 VAC max

: 1 kV/min rms

: ≥ 150 MΩ·km

: ≈ 3.3 nF/km



: < 25 ns/100 m



MECHANICAL CHARACTERISTICS
Cable‑to‑Plug Tensile Strength

Max Pull‑Force

Durability

Propagation Delay 1–250 MHz

Min Bend Radius (without load)

Temp Range (Storage)

Temp Range (Operation)

Flammability

Halogen Content (LSZH)



: ≥ 96 N



: 10 N

: ≥ 1000 mating cycles

: < 25 ns/100 m



: ≥ 25 mm



: –20 °C to +80 °C

: –20 °C to +75 °C

: IEC 60332‑1

: None

REACTION TO FIRE
Flame Retardant Standard

Smoke Emission (LSZH)

Halogen Content (LSZH)

: IEC 60332‑1

: Complies with IEC 61034

: IEC 60754‑1 / 60754‑2 compliant

PART NUMBER

Part Number Description Outer Jacket Material
SCZ-5010C6PCS0012GY SCHNELL CAT6 S/FTP PATCH CORD 0.12 MTR GREY PVC/LSZH
SCZ-5010C6PCS0015GY SCHNELL CAT6 S/FTP PATCH CORD 0.15 MTR GREY PVC/LSZH
SCZ-5010C6PCS002GY SCHNELL CAT6 S/FTP PATCH CORD 0.2 MTR GREY PVC/LSZH
SCZ-5010C6PCS003GY SCHNELL CAT6 S/FTP PATCH CORD 0.3 MTR GREY PVC/LSZH
SCZ-5010C6PCS005GY SCHNELL CAT6 S/FTP PATCH CORD 0.5 MTR GREY PVC/LSZH
SCZ-5010C6PCS01GY SCHNELL CAT6 S/FTP PATCH CORD 1 MTR GREY PVC/LSZH
SCZ-5010C6PCS02GY SCHNELL CAT6 S/FTP PATCH CORD 2 MTR GREY PVC/LSZH
SCZ-5010C6PCS03GY SCHNELL CAT6 S/FTP PATCH CORD 3 MTR GREY PVC/LSZH
SCZ-5010C6PCS05GY SCHNELL CAT6 S/FTP PATCH CORD 5 MTR GREY PVC/LSZH
SCZ-5010C6PCS10GY SCHNELL CAT6 S/FTP PATCH CORD 10 MTR GREY PVC/LSZH
SCZ-5010C6PCS15GY SCHNELL CAT6 S/FTP PATCH CORD 15 MTR GREY PVC/LSZH
SCZ-5010C6PCS20GY SCHNELL CAT6 S/FTP PATCH CORD 20 MTR GREY PVC/LSZH
SCZ-5010C6PCS25GY SCHNELL CAT6 S/FTP PATCH CORD 25 MTR GREY PVC/LSZH
SCZ-5010C6PCS30GY SCHNELL CAT6 S/FTP PATCH CORD 30 MTR GREY PVC/LSZH
