4 CORE 20 AWG SHIELDED MULTI CONDUCTOR CABLE
4 CORE 20 AWG SHIELDED MULTI CONDUCTOR CABLE - Image 2

4 CORE 20 AWG SHIELDED MULTI CONDUCTOR CABLE

SCHNELL 4 Core 20 AWG Shielded Multi-Conductor Cable is designed for reliable data, control, and signal transmission in demanding environments. It features stranded copper conductors, PE insulation, and an overall aluminum foil shield with drain wire, enclosed in a durable PVC or LSZH jacket. Ideal for EMI-sensitive installations requiring superior electrical performance.

📥 DOWNLOAD DATASHEET

Categories: , , Tags: , , Brand:

Description

SCHNELL 4 Core 20 AWG Shielded Multi-Conductor Cable is designed for reliable data, control, and signal transmission in demanding environments. It features stranded copper conductors, PE insulation, and an overall aluminum foil shield with drain wire, enclosed in a durable PVC or LSZH jacket. Ideal for EMI-sensitive installations requiring superior electrical performance.

Key Features

  • Overall aluminum foil shield for EMI protection
  • Durable and flexible construction
  • Suitable for PVC or LSZH jacket options
  • Ideal for low-voltage and control circuits

Key Applications

  • Industrial and commercial control systems
  • Data acquisition and instrumentation
  • Signal and security wiring
  • EMI-sensitive environments

Standards

  • UL 2464
  • ISO/IEC 11801
  • ANSI/TIA-568.2-D
  • IEC 60332-1
  • RoHS Compliant

Part Numbers

Part Number Description
SCZ-9010420SMC1 SCHNELL 4C X 0.52 MM (20 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 100 MTR
SCZ-9010420SMC2 SCHNELL 4C X 0.52 MM (20 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 305 MTR

MATERIAL CONSTRUCTION

Parameter Specification
Conductor Stranded Bare Copper (20 AWG, 7×28)
Core Count 4
Insulation Polyethylene (PE)
Shield Aluminum Foil with Drain Wire
Rip Cord Nylon
Outer Jacket PVC / LSZH
Jacket Color Grey

CHARACTERISTICS

ELECTRICAL CHARACTERISTICS
Nominal Capacitance

Conductor Resistance

Operating Voltage

Dielectric Strength

Cold Bend Test

 : ~72 pF/m

: ~31.5 Ω/km

: 300 V

: ≥ 1000 V for 1 minute

: No cracking at –20°C
PHYSICAL & MECHANICAL CHARACTERISTICS
Jacket Diameter

Insulation Thickness

Jacket Thickness

Pulling Tension

Min. Bending Radius

Operating Temperature

 : ~4.8 mm

: ~0.20 mm

: ~0.40 mm

: 222 N

: 38 mm (minor axis)

: –10°C to +60°C
REACTION TO FIRE
Flame Retardant Jacket

Smoke Emission (LSZH)

Halogen Content

Thermal Resistance

 : IEC 60332-1 Compliant

: Low smoke output

: Halogen-free (LSZH)

: Withstands elevated temp

PART NUMBER

Part Number Description
SCZ-9010420SMC1 SCHNELL 4C X 0.52 MM (20 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 100 MTR
SCZ-9010420SMC2 SCHNELL 4C X 0.52 MM (20 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 305 MTR
