4 CORE 18 AWG SHIELDED MULTI CONDUCTOR CABLE
4 CORE 18 AWG SHIELDED MULTI CONDUCTOR CABLE - Image 2

4 CORE 18 AWG SHIELDED MULTI CONDUCTOR CABLE

SCHNELL 4 Core 18 AWG Shielded Multi Conductor Cable is designed for audio, control, and instrumentation applications requiring protection from external interference. The cable features stranded bare copper conductors, PE insulation, an aluminum foil shield with drain wire, and a durable PVC/LSZH jacket. Suitable for commercial and industrial environments.

📥 DOWNLOAD DATASHEET

Categories: , , Tags: , , Brand:

Description

SCHNELL 4 Core 18 AWG Shielded Multi Conductor Cable is designed for audio, control, and instrumentation applications requiring protection from external interference. The cable features stranded bare copper conductors, PE insulation, an aluminum foil shield with drain wire, and a durable PVC/LSZH jacket. Suitable for commercial and industrial environments.

Key Features

  • Excellent EMI/RFI protection
  • Available with PVC or LSZH jacket
  • Easy stripping and installation
  • Suitable for low-voltage signal/control use

Key Applications

  • Industrial control systems
  • Commercial audio systems
  • Building automation
  • Instrumentation

Standards

  • UL 758
  • RoHS Compliant
  • IEC 60332-1
  • ISO/IEC standards for insulation and flame rating

Part Numbers

Part Number Description
SCZ-9010418SMC1 SCHNELL 4C X 0.75 MM (18 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 100 MTR
SCZ-9010418SMC2 SCHNELL 4C X 0.75 MM (18 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 305 MTR

MATERIAL CONSTRUCTION

Parameter Specification
Conductor Stranded Bare Copper
Core Count 4
Insulation Polyethylene (PE)
Shield Aluminum Foil with Drain Wire
Rip Cord Nylon
Outer Jacket PVC / LSZH
Jacket Color Grey

CHARACTERISTICS

ELECTRICAL CHARACTERISTICS
Nominal Capacitance

Conductor Resistance

Operating Voltage

Current Capacity

Shield Resistance

 : ~77 pF/m

: ≤ 22.3 Ω/km

: 300 V max

: ~5.4 Amps @25°C

: ≤ 25 Ω/km
PHYSICAL & MECHANICAL CHARACTERISTICS
Insulation Thickness

Insulation Diameter

Jacket Thickness

Jacket Diameter

Operating Temperature

Pulling Tension

Min. Bending Radius

 : 0.18 mm

: ~1.90 mm

: ~0.45 mm

: ~6.50 mm

: -10°C to +75°C

: 110 N max

: 6 × OD (Approx. 39 mm)
REACTION TO FIRE
Flame Retardancy

Halogen Content

Smoke Density

Toxicity

 : IEC 60332-1 compliant

: LSZH Available

: IEC 61034 (for LSZH)

: IEC 60754-2 (for LSZH)

PART NUMBER

Part Number Description
SCZ-9010418SMC1 SCHNELL 4C X 0.75 MM (18 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 100 MTR
SCZ-9010418SMC2 SCHNELL 4C X 0.75 MM (18 AWG) SHIELDED MULTI CONDUCTOR CABLE LSZH 305 MTR
